產品型號

風華貼片安規電容

我公司是風華高科授權代理商一站式電子元器件整合供應商，歡迎咨詢！聯系人何先生: 13712101206（微信同號） QQ：3003173476

在線咨詢全國熱線
0769-85325266

產品描述

型號	容量	溫度特性	額定電壓	公差	尺寸	長度	寬度	厚度
SC20B103M302XB	10nF	X7R	250VAC	±20%	2220	5.70±0.40mm	5.00±0.40mm	1.60±0.3mm
SC20B103K302XB	10nF	X7R	250VAC	±10%	2220	5.70±0.40mm	5.00±0.40mm	1.60±0.3mm
SC12B103K302XB	10nF	X7R	250VAC	±10%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC20B472M302YB	4.7nF	X7R	250VAC	±20%	2220	5.70±0.40mm	5.00±0.40mm	2.00±0.3mm
SC08B472M302XB	4.7nF	X7R	250VAC	±20%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC20B472K302YB	4.7nF	X7R	250VAC	±10%	2220	5.70±0.40mm	5.00±0.40mm	2.00±0.3mm
SC12B472K302XB	4.7nF	X7R	250VAC	±10%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC12B472K302YB	4.7nF	X7R	250VAC	±10%	1812	4.50±0.40mm	3.20±0.30mm	2.00±0.3mm
SC08B472K302XB	4.7nF	X7R	250VAC	±10%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC20B332M302YB	3.3nF	X7R	250VAC	±20%	2220	5.70±0.40mm	5.00±0.40mm	2.00±0.3mm
SC20B332K302YB	3.3nF	X7R	250VAC	±10%	2220	5.70±0.40mm	5.00±0.40mm	2.00±0.3mm
SC12B332K302YB	3.3nF	X7R	250VAC	±10%	1812	4.50±0.40mm	3.20±0.30mm	2.00±0.3mm
SC08B332K302XB	3.3nF	X7R	250VAC	±10%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC20B222M302YB	2.2nF	X7R	250VAC	±20%	2220	5.70±0.40mm	5.00±0.40mm	2.00±0.3mm
SC08B222M302YB	2.2nF	X7R	250VAC	±20%	1808	4.50±0.40mm	2.00±0.20mm	2.00±0.3mm
SC20B222K302XB	2.2nF	X7R	250VAC	±10%	2220	5.70±0.40mm	5.00±0.40mm	1.60±0.3mm
SC20B222K302YB	2.2nF	X7R	250VAC	±10%	2220	5.70±0.40mm	5.00±0.40mm	2.00±0.3mm
SC11B222K302YB	2.2nF	X7R	250VAC	±10%	2211	5.70±0.40mm	2.80±0.30mm	2.80±0.3mm
SC12B222K302XB	2.2nF	X7R	250VAC	±10%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC12B222K302YB	2.2nF	X7R	250VAC	±10%	1812	4.50±0.40mm	3.20±0.30mm	2.00±0.3mm
SC08B222K302YB	2.2nF	X7R	250VAC	±10%	1808	4.50±0.40mm	2.00±0.20mm	2.00±0.3mm
SC12B222J302YB	2.2nF	X7R	250VAC	±5%	1812	4.50±0.40mm	3.20±0.30mm	2.00±0.3mm
SC11B152K302YB	1.5nF	X7R	250VAC	±10%	2211	5.70±0.40mm	2.80±0.30mm	1.80±0.3mm
SC12B152K302YB	1.5nF	X7R	250VAC	±10%	1812	4.50±0.40mm	3.20±0.30mm	2.00±0.3mm
SC08B152K302YB	1.5nF	X7R	250VAC	±10%	1808	4.50±0.40mm	2.00±0.20mm	2.00±0.3mm
SC08B152K302XB	1.5nF	X7R	250VAC	±10%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC11B102M302YB	1nF	X7R	250VAC	±20%	2211	5.70±0.40mm	2.80±0.30mm	1.60±0.3mm
SC12B102M302YB	1nF	X7R	250VAC	±20%	1812	4.50±0.40mm	3.20±0.30mm	2.00±0.3mm
SC08B102M302YB	1nF	X7R	250VAC	±20%	1808	4.50±0.40mm	2.00±0.20mm	2.00±0.3mm
SC20B102K302YB	1nF	X7R	250VAC	±10%	2220	5.70±0.40mm	5.00±0.40mm	1.60±0.3mm
SC11B102K302YB	1nF	X7R	250VAC	±10%	2211	5.70±0.40mm	2.80±0.30mm	1.60±0.3mm
SC12B102K302YB	1nF	X7R	250VAC	±10%	1812	4.50±0.40mm	3.20±0.30mm	2.00±0.3mm
SC08B102K302XA	1nF	X7R	250VAC	±10%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC08B102K302YB	1nF	X7R	250VAC	±10%	1808	4.50±0.40mm	2.00±0.20mm	2.00±0.3mm
SC08B821K302YB	820pF	X7R	250VAC	±10%	1808	4.50±0.40mm	2.00±0.20mm	2.00±0.3mm
SC20B681K302XB	680pF	X7R	250VAC	±10%	2220	5.70±0.40mm	5.00±0.40mm	1.60±0.3mm
SC12B561M302YB	560pF	X7R	250VAC	±20%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC08B561K302YB	560pF	X7R	250VAC	±10%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC12B471M302YB	470pF	X7R	250VAC	±20%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC12B471K302YB	470pF	X7R	250VAC	±10%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC08B471K302YB	470pF	X7R	250VAC	±10%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC11B331K302YB	330pF	X7R	250VAC	±10%	2211			1.60±0.3mm
SC12B331K302YB	330pF	X7R	250VAC	±10%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC08B331K302YB	330pF	X7R	250VAC	±10%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC20CG331J302YB	330pF	C0G	250VAC	±5%	2220	5.70±0.40mm	5.00±0.40mm	2.00±0.3mm
SC08B271K302YB	270pF	X7R	250VAC	±10%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC20B221M302YB	220pF	X7R	250VAC	±20%	2220	5.70±0.40mm	5.00±0.40mm	1.60±0.3mm
SC11B221M302YB	220pF	X7R	250VAC	±20%	2211	5.70±0.40mm	2.80±0.30mm	1.60±0.3mm
SC11B221K302YB	220pF	X7R	250VAC	±10%	2211	5.70±0.40mm	2.80±0.30mm	1.60±0.3mm
SC11CG221K302YB	220pF	C0G	250VAC	±10%	2211	5.70±0.40mm	2.80±0.30mm	1.60±0.3mm
SC08B221K302YB	220pF	X7R	250VAC	±10%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC20CG221J302YB	220pF	C0G	250VAC	±5%	2220	5.70±0.40mm	5.00±0.40mm	1.60±0.3mm
SC08B181K302YB	180pF	X7R	250VAC	±10%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC20B151K302YB	150pF	X7R	250VAC	±10%	2220	5.70±0.40mm	5.00±0.40mm	1.60±0.3mm
SC08B151K302YB	150pF	X7R	250VAC	±10%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC12CG121J302YB	120pF	C0G	250VAC	±5%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC12CG121G302YB	120pF	C0G	250VAC	±2%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC12CG121F302YB	120pF	C0G	250VAC	±1%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC08B101M302YB	100pF	X7R	250VAC	±20%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC08B101K302YB	100pF	X7R	250VAC	±10%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC20CG101J302YB	100pF	C0G	250VAC	±5%	2220	5.70±0.40mm	5.00±0.40mm	1.60±0.3mm
SC12CG101J302YB	100pF	C0G	250VAC	±5%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC08CG101J302YB	100pF	C0G	250VAC	±5%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC12CG820J302YB	82pF	C0G	250VAC	±5%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC12CG680J302YB	68pF	C0G	250VAC	±5%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC08CG680J302YB	68pF	C0G	250VAC	±5%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC08CG680G302YB	68pF	C0G	250VAC	±2%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC12CG560J302YB	56pF	C0G	250VAC	±5%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC12CG560F302YB	56pF	C0G	250VAC	±1%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC08CG560F302YB	56pF	C0G	250VAC	±1%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC08CG470J302YB	47pF	C0G	250VAC	±5%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC12CG390J302YB	39pF	C0G	250VAC	±5%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC08CG390J302YB	39pF	C0G	250VAC	±5%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC12CG390F302YB	39pF	C0G	250VAC	±1%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC12CG330K302YB	33pF	C0G	250VAC	±10%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC08CG330K302YB	33pF	C0G	250VAC	±10%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC12CG330J302YB	33pF	C0G	250VAC	±5%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC08CG330J302YB	33pF	C0G	250VAC	±5%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC12CG220J302YB	22pF	C0G	250VAC	±5%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC08CG220J302YB	22pF	C0G	250VAC	±5%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC08CG180F302YB	18pF	C0G	250VAC	±1%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC12CG150J302YB	15pF	C0G	250VAC	±5%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC08CG100J302YB	10pF	C0G	250VAC	±5%	1808	4.50±0.40mm	2.00±0.20mm	1.60±0.3mm
SC12CG8R2J302YB	8.2pF	C0G	250VAC	±5%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC12CG5R0J302YB	5.0pF	C0G	250VAC	±5%	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
SC12CG5R0B302YB	5.0pF	C0G	250VAC	±0.10pF	1812	4.50±0.40mm	3.20±0.30mm	1.60±0.3mm
