產品型號

風華車規電容-安規規格認定型AS系列

我公司是風華高科授權代理商一站式電子元器件整合供應商，歡迎咨詢！聯系人何先生: 13712101206（微信同號） QQ：3003173476

在線咨詢全國熱線
0769-85325266

產品描述

型號	容量	公差	尺寸	額定電壓	溫度特性	長度	寬度	厚度
AS20B472M302YB	4.7nF	±20%	2220	250VAC	X7R	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20B472K302Y2	4.7nF	±10%	2220	250VAC	X7R	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20B472K302YB	4.7nF	±10%	2220	250VAC	X7R	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20B472J302Y2	4.7nF	±5%	2220	250VAC	X7R	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20B472J302YB	4.7nF	±5%	2220	250VAC	X7R	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20B332K302YB	3.3nF	±10%	2220	250VAC	X7R	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20B332K302Y2	3.3nF	±10%	2220	250VAC	X7R	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20B222K302YB	2.2nF	±10%	2220	250VAC	X7R	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20B222K302Y2	2.2nF	±10%	2220	250VAC	X7R	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20B222K202YB	2.2nF	±10%	2220	250VAC	X7R	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20B222K202Y2	2.2nF	±10%	2220	250VAC	X7R	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20B222J302YB	2.2nF	±5%	2220	250VAC	X7R	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20B222J302Y2	2.2nF	±5%	2220	250VAC	X7R	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20B102K302YB	1nF	±10%	2220	250VAC	X7R	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20B102K302Y2	1nF	±10%	2220	250VAC	X7R	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20B102J302YB	1nF	±5%	2220	250VAC	X7R	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20B102J302Y2	1nF	±5%	2220	250VAC	X7R	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20CG681K302YB	680pF	±10%	2220	250VAC	C0G	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20CG681J302Y2	680pF	±5%	2220	250VAC	C0G	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20CG681J302YB	680pF	±5%	2220	250VAC	C0G	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20CG471J302YB	470pF	±5%	2220	250VAC	C0G	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20CG471J302Y2	470pF	±5%	2220	250VAC	C0G	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20CG221K302Y2	220pF	±10%	2220	250VAC	C0G	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20CG221J302Y2	220pF	±5%	2220	250VAC	C0G	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20CG221J302YB	220pF	±5%	2220	250VAC	C0G	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20CG151K302YB	150pF	±10%	2220	250VAC	C0G	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20CG151J302Y2	150pF	±5%	2220	250VAC	C0G	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20CG151J302YB	150pF	±5%	2220	250VAC	C0G	5.70±0.40mm	5.00±0.40mm	2.00±0.30mm
AS20CG101J302Y2	100pF	±5%	2220	250VAC	C0G	5.70±0.40mm	5.00±0.40mm	1.60±0.30mm
AS20CG101J302YB	100pF	±5%	2220	250VAC	C0G	5.70±0.40mm	5.00±0.40mm	1.60±0.30mm
AS20CG101J302X1	100pF	±5%	2220	250VAC	C0G	5.70±0.40mm	5.00±0.40mm	1.60±0.30mm
AS20CG101J302XA	100pF	±5%	2220	250VAC	C0G	5.70±0.40mm	5.00±0.40mm	1.60±0.30mm
AS08CG470J302YB	47pF	±5%	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG470J302Y2	47pF	±5%	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG330J302YB	33pF	±5%	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG330J302Y2	33pF	±5%	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG220J302YB	22pF	±5%	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG220J302Y2	22pF	±5%	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG150J302YB	15pF	±5%	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG150J302Y2	15pF	±5%	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG120J302Y2	12pF	±5%	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG120J302YB	12pF	±5%	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG100J302Y2	10pF	±5%	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG100J302YB	10pF	±5%	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG8R0B302YB	8.0pF	±0.10pF	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG8R0B302Y2	8.0pF	±0.10pF	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG6R8B302YB	6.8pF	±0.10pF	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG6R8B302Y2	6.8pF	±0.10pF	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG5R6B302YB	5.6pF	±0.10pF	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG5R6B302Y2	5.6pF	±0.10pF	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG5R0B302YB	5.0pF	±0.10pF	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
AS08CG5R0B302Y2	5.0pF	±0.10pF	1808	250VAC	C0G	4.50±0.40mm	2.00±0.20mm	1.60±0.30mm
